The
topic commands use iceoryx2 service discovery, so they work from any
directory, no workspace required. Run them in a second terminal while a graph
is running.List and inspect live topics
cerulion topic list prints this machine’s shared-memory topics first, then the robots on your account and their topics, on one LAN or across networks.
No active local topics.
cerulion topic info <topic> prints one topic’s schema and its last sequence number and timestamp:
Watch messages with echo
cerulion topic echo <topic> subscribes and prints each message until you press Ctrl+C.
# seq=.. ts=..ns schema=0x.. size=.. comment, a # <type> comment, the fields, then ---. An array longer than --truncate-length (default 128) ends in !truncated <n>, the number of elements left out. Every type prints its fields this way, sensor_msgs/Image included. A frame no known schema names prints # comment lines that say why, with a hex preview of its first 64 payload bytes.
Measure publish rate
cerulion topic hz <topic> measures how often a topic publishes, until Ctrl+C.
For the periodic camera created with
--policy period_ms=33, topic hz
should report roughly 30 Hz.Find topics by type, and measure bandwidth
cerulion topic type <topic> prints a topic’s message type, and cerulion topic find <type> lists every topic that carries one:
cerulion topic bw <topic> measures how many bytes a topic carries per second, over its newest 100 messages by default (--window N changes that):
Publish a test message
cerulion topic pub <topic> <type> <message> publishes one message given as JSON or YAML. --times N and --rate HZ publish several:
Save a camera frame
cerulion topic snapshot <topic> -o <file> saves the newest frame of a sensor_msgs/Image or sensor_msgs/CompressedImage topic as a JPEG:
Open the interactive dashboard
cerulion tui launches an interactive terminal dashboard. Logging is suppressed while the TUI is open.
Keep a record instead of watching
echo and hz answer questions about now. To keep the data, record the run to an MCAP bag and inspect it afterwards; see Record and replay a run.
Clean up stale services
iceoryx2 keeps on-disk bookkeeping for each node. When a graph’s topology changes between runs, stale entries from dead nodes can cause discovery errors.cerulion clean removes the bookkeeping dead Cerulion processes left behind; live nodes are left alone. It needs no account and reaches no network. It prints cleanup counts and per-cause remediation, and names every node it could not reclaim together with the reason. A graph that stops normally already runs a short cleanup pass of its own as it exits, so reach for this command mainly after a run that was killed, or when you want everything cleared at once.
cerulion clean --report-only deletes nothing: it lists what a plain cerulion clean would remove and ends with Report only: nothing was removed.
