Define a node

A node is a Rust crate with a #[cerulion_node] struct and a tick() method. This guide takes you from cerulion node create to a node that reads inputs, writes outputs, and is ready to stage into a graph. For the full attribute and policy grammar, see the node macro reference and trigger policies reference.

Run these commands from inside a workspace (a directory with a [workspace] Cargo.toml and a graphs/ folder). Create one with cerulion workspace create <name>.

Create the node type

cerulion node create <node_type> scaffolds nodes/<node_type>/ with a Cargo.toml (cdylib) and a src/lib.rs macro template. The type name becomes the folder name and, PascalCased, the struct name. It must be non-empty, alphanumeric or underscore, and must not start with a digit. Add ports while creating the node:

Flag	Value names	Meaning
`-o` / `--output`	`SCHEMA NAME`	Add one output port.
`-i` / `--input`	`SCHEMA NAME`	Add one regular input port.
`-T` / `--trigger-input`	`SCHEMA NAME`	Add one trigger input (fires the node on data arrival).
`--policy`	`SPEC`	Set the trigger policy (see below).

Each of -o, -i, and -T takes two values (a schema and a name), and you may pass at most one of each per create call. Add more ports later with node modify. Schemas accept both sensor_msgs/Image and sensor_msgs::Image; both canonicalize to the slash form.

Pick a trigger policy

The trigger policy decides when the node fires. Pass it with --policy SPEC:

`--policy` SPEC	Fires when…
`period_ms=N`	Every N milliseconds (N > 0).
`sync_window_ms=N`	All trigger inputs have a message within an N-ms window.
`external`	The node fires itself off a non-Cerulion signal (a device fd or a blocking SDK call).
`data_trigger=NAME`	The named trigger input receives data.

Conceptual close-up of a robot joint sensor and its signal indicator.

How the policy defaults when you omit --policy depends on the node’s inputs:

0 inputs (no -i, no -T): a source-only node must declare a non-data policy. cerulion node create errors otherwise.
1+ inputs via -i only: no node-level policy is written; the runtime fires on any input arrival and emits a graph-build warning.
-T set: the policy becomes data_trigger for that trigger input.

A source-only node (zero inputs) has nothing to fire it, so you must give it an explicit non-data policy with --policy period_ms=N or --policy external. Combining a non-data --policy with -T is a conflict and errors.

Create a periodic source node

A camera with no inputs needs a period:

cerulion node create camera -o sensor_msgs/Image image --policy period_ms=33

Created node type 'camera'

Create a data-triggered consumer

A detector that fires whenever an image arrives:

cerulion node create detector -T sensor_msgs/Image image -o geometry_msgs/PoseStamped detection

Created node type 'detector'

Write the tick()

Open nodes/<node_type>/src/lib.rs. The template pairs two macros:

#[cerulion_node(...)] on the struct declares the node and its trigger policy, and generates the glue that lets cerulion graph run load it.
#[cerulion_node_impl] on the adjacent impl block lets tick() use plain field access for ports — reads and writes go directly to shared memory, zero-copy. It takes no arguments, and the struct must appear before the impl block.

Import everything from the prelude, and import the message types you use:

use cerulion_core::prelude::*;
use native_ros2_messages::geometry_msgs::Vector3;
use native_ros2_messages::sensor_msgs::LaserScan;

#[cerulion_node(period_ms = 10)]      // period-driven; reads the latest scan each tick
#[derive(Default)]
struct SafetyController {
    #[input(depth = 1)]               // regular input (use `trigger` for data-triggered)
    scan: LaserScan,

    #[output]                         // Vector3 = fixed-only schema (pub x/y/z: f64)
    linear_velocity: Vector3,
}

#[cerulion_node_impl]
impl SafetyController {
    fn tick(&mut self) -> Result<(), NodeError> {
        // Variable field read via typed accessor:
        let obstacle_close = self.scan.ranges().iter().any(|&r| r < 0.5);
        // Fixed field write; goes straight to shared memory:
        self.linear_velocity.x = if obstacle_close { 0.0 } else { 0.3 };
        Ok(())
    }
}

Fixed vs variable fields

How you write an output field depends on whether it is fixed-size or variable-length:

Fixed primitive fields (for example x, y, z, height, width) are written directly: self.linear_velocity.x = 0.3;. The write goes straight to shared memory.
Variable-length fields (string, T[]) are also written with plain assignment, but they are read through an accessor — self.scan.ranges() — because their length is only known at runtime.

#[output] is the only form you need, for every schema:

use cerulion_core::prelude::*;
use native_ros2_messages::sensor_msgs::Image;

#[cerulion_node(period_ms = 33)]
#[derive(Default)]
struct Camera {
    #[output]
    image: Image,
}

#[cerulion_node_impl]
impl Camera {
    fn tick(&mut self) -> Result<(), NodeError> {
        self.image.height = 480;                    // fixed field, direct write
        self.image.width = 640;                     // fixed field, direct write
        self.image.encoding = "rgb8";               // variable field, plain assignment
        self.image.header.frame_id = "camera";      // nested field, same
        Ok(())
    }
}

Earlier versions required you to list variable fields in the attribute (#[output(data, encoding)]) and to wrap nested ones in complex(...). Both forms are gone — write #[output] and assign the fields.

Only the outputs you actually touch during a tick are published, so a node can hold a channel silent by leaving it alone. A tick that returns Err publishes nothing at all.

Zero-copy write for large payloads: plain = assignment copies your buffer once. For camera drivers or codecs that can write directly into a destination buffer, use fill_from instead — your producer receives the destination buffer itself, skipping the copy:

self.image.data.fill_from(|buf: &mut [u8]| {
    let n = driver.read_frame_into(buf)?;
    Ok(n)
})?;

FillFrom and SliceSource are re-exported from cerulion_core::prelude. See the node macro reference for details.

Build the node

cerulion node build <node_type> compiles the crate into a cdylib. Add --release for an optimized build.

node build shells out to cargo, so cargo must be on your PATH. A missing toolchain is reported as such and names what to install: Rust 1.93 or later from rustup, plus a C linker — build-essential on Ubuntu and Debian, the Xcode Command Line Tools on macOS.

cerulion node build camera
cerulion node build detector

Built 'camera'

A successful build prints Built '<node_type>'. On failure the CLI prints Error: with the cargo output, and no cdylib is produced.

Inspect and adjust

Use these commands to review and edit node types after creation.

List node types

cerulion node list prints a table of types with input/output counts and a short policy label.

cerulion node list

TYPE       INPUTS  OUTPUTS  POLICY
camera     0       1        period 33ms
detector   1       1        trigger:image

Show one node's details

cerulion node info <node_type> prints the type, policy, and each port with its schema. Metadata is parsed from src/lib.rs; there is no sidecar file.

cerulion node info detector

Add ports later

cerulion node modify <node_type> mutates src/lib.rs in place, preserving the tick body and comments. It takes the same -i, -T, -o, and --policy flags (at most one of each per call).

cerulion node modify detector -i sensor_msgs/Imu imu

Added input 'imu' to 'detector'

Adding a trigger input with -T also sets the data_trigger policy. To make a node externally triggered, use --policy external.

Delete a node type

cerulion node delete <node_type> removes the node crate and its workspace member entry.

cerulion node delete detector

Deleted node type 'detector'

Next steps

Wire and run a graph

Stage these node types into a graph and run it.

Trigger policies

The full --policy grammar and defaulting matrix.

Backpressure and deadlines

Queue policies, rate caps, and reacting to late data in code.
